Item Details
Item specification details
Property Value
Item Id 408928
Item #: 408928
Item: INTERPACK USA 2024-SB Case Sealer
Model #: USA2024-SB
Serial #: 1M09417L037
Year Built: N/A
Location: Illinois
Price: $7,195.00
Description

The USA 2024-SB is a uniform semi-automatic case sealer. This is an adjustable, operator-fed machine
that processes same-size RSC boxes. This case sealer features premium side belt drives, processing a
wider range of cases with a belt speed of 82 FPM. By incorporating standard multi-wheel top squeezers, the major flaps are compressed before taping, offering a clean-looking, uniform finish.

It is equipped with Interpack’s top-of-the-line tape head, which was designed for fast changeover
and easy cleaning. The top tape head tips up to simplify roll replacement. The upper tape and mast is
adjusted using a slide and lock mechanism. The selectable floating upper head processes mild overfills. The upper head rests on dual columns for maximum stability. By offsetting the upper and lower taping heads, the USA 2024-SB can process cases as low as 3 ½”.

The self-tensioning, self-tracking dual side belts can be replaced in just a few simple steps. The side belts capture the case between two moving moving belts, reducing the force on the case. The belts are driven by twin 1/3 HP drive motors capable of 24/7 operation.

Specs:
Overall Machine Dimensions (L x W x H): 44 ½” (1130 mm) x 41 ¾” (1053 mm) x 73” (1854 mm)
Minimum Package Dimensions (L x W x H): 6” (152 mm) x 3 ½” (89 mm) x 3 ½” (89 mm)
Maximum Package Dimensions (L x W x H): ∞ x 20” (508 mm) x 24” (610 mm)
Conveyor Height: 24” - 30” (610 mm - 762 mm)
Belt Speed: Up to 82 FPM (.42 Meters/Sec)
Shipping Weight: 560 lbs (254 kg)
Electrical Requirements: 110 Volts, 1PH, 60 Hz

Additional Prep Fees May Apply
Shipping
Item shipping dimensions and specifications
Dimension Measurement
Height: N/A
Width: N/A
Length: N/A
Weight: N/A
Prep Fee: N/A
Registered customers can request free US domestic shipping quotes. Quotes take 1-3 business days to process.
